Why You Need Pancake Type of Load Cells and Transducers
One of the most important aspects of purchasing the right load cells and transducers is to make the correct choice when choosing the type or sensors to use. Although there are very many types of sensors that you can use, each has its own function and condition through which it can work. For this reason, you will be required to know the various types of load cells any load cell manufacturer produces and how they are used. The most commonly used type of load cell is the pancake sensors. These are sensors used in low profile situations where high precision is required. Additionally, it works best through tension or compression load cells.
The first thing you need to know about the pancake load cells is the fact that they are called the low profile load cells. It works best in an environment where you require high accuracy. However, it is not very sensitive to load conditions. The other thing you will be able to notice about this load cell is the fact that it comes with multiple shear struts. For pancake load cells that are required for a lower capacity these come designed with bending beams.
Like in all other types of load cells it is important that the manufacturer adheres to all the required standards set for the manufacturer of load cells used in different industries. In this case, if the pancake cells are well designed, they will be able to be even less sensitive to irrelevant loads or moments. This way, it will provide a more accurate result. Additionally, the load cells must be able to guarantee you the most satisfactorily results at a competitive price.
The other features that you can use to establish whether you have a pancake load cell or not is to establish whether it has multiple thru holes and a female thread thru at the center. The multiple thru holes are used to make mounting easy and are usually found in the outer ring of the load cell. If you fix the outside mounting holes, you will be in a position to use the low profile load cell even in cases of tension. To be able to use in for both tension and compression, you will have to add a tension plate. The other standard features that you can expect on the pancake load cells include the metric thread, and also a quick disconnect. However, there are those manufacturers who prefer to add the built-in amplifiers that provide different options for plug in and play.
There are very many manufacturers who produce these load cells. Additionally, it is possible to have each of these manufacturers producing load cells of various capacities. For this reason, you can have a load cell supplier who has more than one variety of the pancake load cells. The most standard capacity that you can get for this kind of load cells includes capacities of not less than 50lbs and a maximum of 1 million lbs. You can be able to use the pancake load cells in case where you require endurance testing.
